H.P. Category	20
Engine Make	Field Marshal
Type	Diesel, Four Stroke DI Engine
No. of Cylinders	1
Bore/Stroke	100/114 mm
Rated Speed	2300 RPM
Max. Torque Speed	1200 + 1400 RPM
Air Cleaner	Oil Bath Type
Cooling System	Water cooled
Clutch System	Single Clutch
Hyd. Pump	Gear Type
Lifting Capacity	500 kg at Lower Link Ends
Electrical System	12 Volts-65 Ah-Battery Self Starter Motor & Alternator
Tyre
Front	5.20 x 14
Rear	8.00 x 18
Wheel Track	Front : 940 , Rear : 830
Measurement
Length	2520 mm
Width	1050 mm
Height	1240 mm
upto steering
Min. Ground Clearance	210 mm
Weight	800 kg
P.T.O.
1. PTO Power (ps)	12.92@2300 Engine RPM
2. No. of Suplines	6
3. PTO Speed	540@2100 RPM
Driver's Seat	Adjustable
Transmission
No. of Gear Speeds	6 Forward 2 Reverse
Steering	Mechanical - Recirculating ball type (optional)
Steering wheel dia	380 mm
Min. Turning radius	2.2 m
Brake Type	Oil immersed multiple discs
Actuation	Mechanical, independent right/left or combined
Parking	Through hand lever, by locking brake pedals
